Skid loader -YANMA engine -XC770K

BRAND:XCMG
Description
Rated load(kg)：1250
Tipping load (kg):2500
Operating weight(kg): 3700/3600
Maximum breakout force(kN): 22
Maximum traction(kN):≥32
Engine
Manufacturer：
Model：YANMAR
Rated power：4TNV98T
Rated speed：82.2/61.3
Cooling mode：2500
Cooling mode：Liquid
Discharge：Three stages
Performance parameter
Operation mode：Pilot hydraulic control & multifunction electronic control
Tire standard：12-16.5
Maximum speed（km/h）：11/22
The main parameters
Maximum operating height(mm) :4180
Bucket hinge pin height(mm) :3205
Cabin top height (mm) :1960
Maximum horizontal height of bucket bottom (mm) :2997
Length without bucket (mm) :3050
Length with bucket (mm) :3750
Toppling angle (°):40
Maximum unloading height (mm) :2450
Ground-bucket angle (°):30
Rotating angle of bucket at highest point (°):83
Unloading distance (mm) :570
Wheel base (mm) :1320
Departure angle (°):25
Ground clearance (mm) :205
Front radius of turning circle (without bucket )(mm) :1370
Front radius of turning circle (with bucket) (mm) :2230
Rear radius of turning circle (mm) :1840
Length of tail (mm) :1105
Wheel track (mm) :1500
Tire edge width (mm) :1807
Bucket edge width (mm) :2000
Bucket capacity (stacking height) (mm) :0.6
Diesel tank capacity (L):108
Capacity of hydraulic oil tank(L):80
Engine: WP4.1 100HP
Hydraulic flow 100.4L/min
Operation weight 3700kg
Lifting capacity 1250kg
